Description:
An anti-lock brake system (ABS) is an automatic control system designed to prevent wheel lock-up during braking. It comprises three key components: Sensors, electronic control units, and brake pressure regulators. The system functions by regulating brake pressure to maintain optimal tire-to-road grip, enhancing vehicle control and reducing stopping distances.
A critical component of the abs system is the magnetic ring. Installed on the vehicle's axle, it measures wheel speed through a sensor and transmits this data to the electronic control unit. The unit processes the information to calculate vehicle speed and determines when to adjust brake pressure. During braking, the electronic control unit rapidly modulates brake pressure (up to 10 times per second) to prevent wheel lock-up.
This product is applicable to automotive engine crankshafts and ABS systems for automotive transmissions.
Specification:
Magnetization method
Axial, Rotary
Radial, Rotary
Inter, Radial, Rotary
| Shaft Dimeter (mm) |
Thick (mm) |
Metarail | Metal Carriers | OE Number |
|---|---|---|---|---|
| 84.7 | 8.8 | Rubber Magnets | Y | - |
| 180 | 9 | Rubber Magnets | Y | - |
| 84.35 | 6.8 | Rubber Magnets | N | 7701472838/8200367094S1 |
| 77.9 | 8.2 | Rubber Magnets | N | 4249.45/4549.23/4549.19 |
| 68.85 | 8.4 | Rubber Magnets | N | 9809248280/3349.09 |
| 69.9 | 6.8 | Rubber Magnets | N | 432001539R/9654003280 |
| 66.4 | 11 | Rubber Magnets | N | 0530448/09156203 |
| 72 | 10.8 | Rubber Magnets | N | - |
Millimeters to inches conversion table
The fraction inches are rounded to 1/64 resolution.
| Millimeters(mm) | Inches(") (decimal) |
Inches(") (fraction) |
|---|---|---|
| 0.01mm | 0.0004″ | 0″ |
| 0.1 mm | 0.0039 ″ | 0 ″ |
| 1 mm | 0.0394 ″ | 3/64 ″ |
| 2 mm | 0.0787 ″ | 5/64 ″ |
| 3 mm | 0.1181 ″ | 1/8 ″ |
| 4 mm | 0.1575 ″ | 5/32 ″ |
| 5 mm | 0.1969 ″ | 13/64 ″ |
| 6 mm | 0.2362 ″ | 15/64 ″ |
| 7 mm | 0.2756 ″ | 9/32 ″ |
| 8 mm | 0.3150 ″ | 5/16 ″ |
| 9 mm | 0.3543 ″ | 23/64 ″ |
| 10 mm | 0.3937 ″ | 25/64 ″ |
| 20 mm | 0.7874 ″ | 25/32 ″ |
| 30 mm | 1.1811 ″ | 1 3/16 ″ |
| 40 mm | 1.5748 ″ | 1 37/64 ″ |
| 50 mm | 1.9685 ″ | 1 31/32 ″ |
| 60 mm | 2.3622 ″ | 2 23/64 ″ |
| 70 mm | 2.7559 ″ | 2 3/4 ″ |
| 80 mm | 3.1496 ″ | 3 5/32 ″ |
| 90 mm | 3.5433 ″ | 3 35/64 ″ |
| 100 mm | 3.9370 ″ | 3 15/16 ″ |
Note:If you require sensor recommendations, please contact our sales representatives and we will provide you with suggestions for pairing them.
