Introduction Magnetic Gears/Couplings for PVC (Polyvinyl chloride)
Magnetic transmission gears are non-contact power transmission mechanisms making use of the attraction and repulsion properties of the magnets.
PVC magnetic gear/coupling (PVT Series) is fully wrapped with PVC material, and the seams are all sealed, so it can be used in strong acid and alkali environments.The maximum operating temperature of PVC (Polyvinyl chloride) magnetic gear/coupling is: 60C(140F) .
Their surface magnetism is not as strong as metal-wrapped magnetic gear/coupling. Therefore, if the surface magnetism is high, we recommend that you customize a magnetic gear wrapped in titanium.
This type of magnetic gear/coupling can be customized with shaft diameters of various shapes and sizes, but it only has one shaft fixing method, please refer to: Type A.
Product Parameter
| Part Number | O.D (mm) | Pole (Qty) | I.D (mm) | L | K | M | Cross drive torque output (Gap 0.5mm) | Parallel drive torque output ( Gap 0.5mm ) |
|---|---|---|---|---|---|---|---|---|
| PVT | 23 | 8P | 8,10 | 26 | 10.5 | M4 | 0.07N. m | 0.1N.m |
| PVT | 28 | 8P | 8,10,12 | 25 | 10 | M4 | 0.11N. m | 0.23N.m |
| PVT | 30 | 8P | 8,10,12,15 | 30 | 11. 5 | M5 | 0.14 N. m | 0.31N.m |
| PVT | 32 | 10P | 8,10,12,15 | 31 | 12 | M5 | 0.18N.m | 0.33N.m |
| PVT | 37 | 8P | 10,12,15,20 | 34.5 | 14 | M5 | 0.32N.m | 0.59N. m |
| PVT | 41 | 8P | 15,20 | 39 | 16 | M5 | 0.48 N.m | 0.77N.m |
| PVT | 44 | 12P | 15,20 | 34 | 13.5 | M5 | 0.45 N.m | 0.72N.m |
| PVT | 47 | 10P | 15,20,25 | 38 | 15.5 | M5 | 0.78 N.m | 0.98N.m |
| PVT | 55 | 10P | 20,25,30 | 28 | 15.5 | M5 | 0.87 N. m | 1.54N.m |
Advantages of magnetic gears products
- Very low noise and vibration
- No wear No dust
- No heat generation
- Oil-free
- Power transmission through wall
- Torque limiter function
- Easy attaching and detaching
- Large tolerance for declination and eccentricity
Support a wide variety of magnetic gears
- In order to meet the customer s specifications such as anti-corrosion and heat resistance, We offer a variety of materials and surface treatments suited for various atmospheres.
- We can customize magnets with high magnetic force and anti-rust effects are selected depending on the applications.
- We are willing to accept the unitization request and co-develop with customers.
