Original factory, accept visitors
Free design, technical support
Quality assurance, one year warranty
Our PVC magnetic conveyor gear is manufactured using rigid PVC, a versatile and widely-used thermoplastic polymer known for its durability and chemical resistance. PVC is the world's third-most produced synthetic plastic, and is commonly used in construction, packaging, and various industrial applications.
Benefits of PVC magnetic conveyor gear:
- Chemical Resistance: Excellent resistance to acids, alkalis, and corrosion, making them ideal for chemical processing applications.
- Durability: High resistance to water pressure, external pressure, and impact.
- Electrical Insulation: Excellent electrical insulation properties, suitable for use in electrical environments.
- Water Quality: Non-contaminating to water, as verified by dissolution tests.
| Part Number | O.D (mm) | Pole (Qty) | I.D (mm) | L | K | M | Cross drive torque output (Gap 0.5mm) | Parallel drive torque output ( Gap 0.5mm ) |
|---|---|---|---|---|---|---|---|---|
| PVT | 23 | 8P | 8,10 | 26 | 10.5 | M4 | 0.07N. m | 0.1N.m |
| PVT | 28 | 8P | 8,10,12 | 25 | 10 | M4 | 0.11N. m | 0.23N.m |
| PVT | 30 | 8P | 8,10,12,15 | 30 | 11. 5 | M5 | 0.14 N. m | 0.31N.m |
| PVT | 32 | 10P | 8,10,12,15 | 31 | 12 | M5 | 0.18N.m | 0.33N.m |
| PVT | 37 | 8P | 10,12,15,20 | 34.5 | 14 | M5 | 0.32N.m | 0.59N. m |
| PVT | 41 | 8P | 15,20 | 39 | 16 | M5 | 0.48 N.m | 0.77N.m |
| PVT | 44 | 12P | 15,20 | 34 | 13.5 | M5 | 0.45 N.m | 0.72N.m |
| PVT | 47 | 10P | 15,20,25 | 38 | 15.5 | M5 | 0.78 N.m | 0.98N.m |
| PVT | 55 | 10P | 20,25,30 | 28 | 15.5 | M5 | 0.87 N. m | 1.54N.m |
- Applications:
- Limitations:
-
Key Features of Rigid PVC:
Note: For more specific applications or customization options, please consult our technical team.
Faq for toothless magnetic gears
What are the applications for magnetic gears?
Magnetic gears are utilized in conveyors frequently. They serve to transport items such as LCDs, [...]
Learn More...Are there any precautions when installing magnetic gears?
Please secure the magnetic product to the shaft after placing a non-magnetic, high-rigidity, high-sliding spacer. [...]
Learn More...What should you pay attention to when choosing a non-contact transmission?
The weight of the shaft used in the design, Natural rotational resistance (bearing grease, etc.) [...]
Learn More...Can non-contact transmissions generate heat or static electricity at high rotational speeds?
Due to its non-contact design, magnetic transmission is not suitable for operation at high rotational [...]
Learn More...Can Magnetic Drives( Gear/Coupling ) Work with High RPM Applications?
Due to its no contact design, Magnetic Drives( Gear/Coupling ) are not designed to run [...]
Learn More...What is the service life of non-contact transmission devices?
Because it is made of permanent magnets, it can be used for 100 years under [...]
Learn More...What is the maximum gap size allowed for non-contact magnetic drive gears?
The size of the magnetic wheel is different, and the gap will be different. Generally, [...]
Learn More...Will there be any backlash while using the Magnetic Drives( Gear/ Couplings ) ?
This product generates no backlash. Most rotary transmission components like belts and gears are known [...]
Learn More...
How much misalignment is allowed with Magnetic Gear Transmission Drives?
It is critical that the magnetic poles on each unit are properly aligned, but how [...]
Learn More...
